optional air conditioning system in conjunction with the FAN switch. Press the top of the switch to turn air conditioner on. Press the bottom of the switch to turn the air conditioner off.
Beacon Light The beacon light (14) is located on a bracket on the left rear side of the machine beside the hoists. It is operational anytime the ignition switch is in the ACC or RUN position.
Crane’s Electrical System Diagnostic Connector This connector (35) is mounted on the side of the right side console by the operator’s right leg. It is used for servicing the engine ECM, transmission ECM or crane’s electrical system. NOTE:
A laptop computer with appropriate cable and electrical system software are required.
Fuse Panel The fuse panel (13) is located under the cover panel on the back wall of the cab behind the seat. It contains 16 fuses and 4 relays that protect and control various circuits of the superstructure.
