TMS800E OPERATOR’S MANUAL
OPERATING CONTROLS AND PROCEDURES
To retract the center front stabilizer, push the bottom of the outrigger extend/retract switch, then push the bottom of the center front stabilizer switch.
To retract the right front stabilizer, push the bottom of the outrigger extend/retract switch (44) and the bottom of the right front outrigger switch.
NOTE:
Left Rear Outrigger Switch
The center front stabilizer will retract anytime the extend/retract switch is positioned to the retract position.
Left Front Outrigger Switch The left front outrigger switch (11) is located on the right side console. It is a three-position switch used to extend or retract the left front stabilizer and extension cylinders. It must be used in conjunction with the outrigger extend/retract switch.
The left rear outrigger switch (43) is located on the right side console. It is a three-position switch used to extend or retract the left rear stabilizer and extension cylinders. It must be used in conjunction with the outrigger extend/retract switch. To extend the left rear outrigger beam, push the top of the outrigger extend/retract switch (44) and the top of the left rear outrigger switch.
To extend the left front outrigger beam, push the top of the outrigger extend/retract switch (44) and the top of the left front outrigger switch.
To retract the left rear outrigger beam, push the bottom of the outrigger extend/retract switch (44) and the top of the left rear outrigger switch.
To retract the left front outrigger beam, push the bottom of the outrigger extend/retract switch (44) and the top of the left front outrigger switch.
To extend the left rear stabilizer, push the top of the outrigger extend/retract switch (44) and the bottom of the left rear outrigger switch.
To extend the left front stabilizer, push the top of the outrigger extend/retract switch (44) and the bottom of the left front outrigger switch.
To retract the left rear stabilizer, push the bottom of the outrigger extend/retract switch (44) and the bottom of the left rear outrigger switch.
To retract the left front stabilizer, push the bottom of the outrigger extend/retract switch (44) and the bottom of the left front outrigger switch.
Right Rear Outrigger Switch
Right Front Outrigger Switch The right front outrigger switch (19) is located on the right side console. It is a three-position switch used to extend or retract the right front stabilizer and extension cylinders. It must be used in conjunction with the outrigger extend/retract switch.
The right rear outrigger switch (42) is located on the right side console. It is a three-position switch used to extend or retract the right rear stabilizer and extension cylinders. It must be used in conjunction with the outrigger extend/retract switch. To extend the right rear outrigger beam, push the top of the outrigger extend/retract switch (44) and the top of the right rear outrigger switch.
To extend the right front outrigger beam, push the top of the outrigger extend/retract switch (44) and the top of the right front outrigger switch.
To retract the right rear outrigger beam, push the bottom of the outrigger extend/retract switch (44) and the top of the right rear outrigger switch.
To retract the right front outrigger beam, push the bottom of the outrigger extend/retract switch (44) and the top of the right front outrigger switch.
To extend the right rear stabilizer, push the top of the outrigger extend/retract switch (44) and the bottom of the right rear outrigger switch.
To extend the right front stabilizer, push the top of the outrigger extend/retract switch (44) and the bottom of the right front outrigger switch.
To retract the right rear stabilizer, push the bottom of the outrigger extend/retract switch (44) and the bottom of the right rear outrigger switch.
GROVE
Published 12-22-2008, Control # 107-09
3-13
3
