TMS800E OPERATOR’S MANUAL
LUBRICATION
15. Rear Aluminum Wheel Pilots
drain plug every 80,000 km (50,000 mi) or 2 years, whichever interval occurs first
Lube Type - ASC Lube Interval - When wheels are removed for service.
.
Lube Amount - Generously coat the wheel pilot or hub pads with anti-seize (ASC) compound. Do not apply anti-seize compound to the face of the wheel of the hub. Application - Brush on; 8 places 16. Front Rear Axle Differential ___ Correct: Lube level at bottom of filler hole. - - - Incorrect: Lube level below filler hole.
Lube Type - SSGL-5 Lube Interval - Check lubricant level every 250 hours and refill as necessary. Drain, fill, change filter, and clean magnetic drain plug every 80,000 km (50,000 mi) or 2 years, whichever interval occurs first.
6626
FIGURE 5-1
CAUTION
CAUTION
Use of non-semi-synthetic lubricant may damage components and/or invalidate published lubrication intervals.
Use of non-semi-synthetic lubricant may damage components and/or invalidate published lubrication intervals.
CAUTION
CAUTION
Axle fluid levels shall be adjusted to bottom of fill plug threads. Check with crane on level ground, at its normal ride height, cold or room temperature oil only.
Axle fluid levels shall be adjusted to bottom of fill plug threads. Check with crane on level ground, at its normal ride height, cold or room temperature oil only.
CAUTION
CAUTION
If the makeup amount is substantially more than 0.23 liter (0.5 pint) check for leaks.
If the makeup amount is substantially more than 0.23 liter (0.5 pint) check for leaks.
Lube Amount - Capacity - 27 liters (57 pints) Normal makeup - less than 0.23 liter (0.5 pint)
Lube Amount - Capacity - 17.5 liters (37 pints) Normal makeup - less than 0.23 liter (0.5 pint)
Application - Fill to bottom of fill plug threads.
Application - Fill to bottom of fill plug threads. 18. Rear Axle Brake Slack Adjusters
NOTE:
NOTE:
Lube level (Figure 5-1) close enough to the hole to be seen or touched is not sufficient. It must be level with the hole.
Lube Type - EP-MPG
When checking lube level, also check and clean housing breathers.
Lube Amount - Until grease extrudes
Figure 5-1 pertains to the differentials and the planetary hubs and wheel bearings.
Lube Interval - 1000 hours
19. Rear Axle Brake Camshafts Lube Type - EP-MPG
17. Rear Rear Axle Differential Lube Type - SSGL-5
Lube Interval - 1000 hours
Lube Interval - Check lubricant level every 250 hours and refill as necessary. Drain, refill, and clean magnetic
Lube Amount - Until grease extrudes
GROVE
5
Application - 4 grease fittings
Application - 4 grease fittings
Published 12-22-2008, Control # 107-09
5-7
