Bottom View
#
14
#
Item
Item
Description
Description
1
Battery release latches
Release the battery for removal
2
Optical drive bay release latch
Releases the optical drive for removal
3
Cooling fan
Helps keep the computer cool Note: Do not cover or obstruct the opening of the fan.
4
Optical drive bay
Houses the computer's optical drive.
5
Wireless LAN bay
Houses the computer's wireless LAN
6
Hard disk bay
Houses the computer's hard disk (secured by a screw)
7
Battery bay
Houses the computer's battery pack
8
Memory compartment
Houses the computer's main memory
