System Components RTLO-xx913 Model Splitter Cylinder Assembly LO Range or HI Range Low Split - With the splitter control button in the "rearward" position, no air is supplied to the splitter cylinder cover top port (1). The constant air from the air filter/regulator assembly (2) moves the splitter piston rearward, disengaging the rear auxiliary drive gear (3).
System Components
HI Range High Split - With the splitter control button in the "forward" position, air is supplied to the splitter cylinder cover top port (1), moving the splitter piston forward, engaging the rear auxiliary drive gear (2).
183
