System Components RTLO-xx610 Model Splitter Cylinder Assembly (Latest Design) Odd Numbered Gear Positions (1, 3, 5, 7, 9) With the Roadranger valve button in the rearward position, no air is supplied to the splitter cylinder cover port (1), moving the piston rearward, disengaging splitter gearing (2).
System Components
Even Numbered Gear Positions (2, 4, 6, 8, 10) With the Roadranger valve button in the forward position, air is supplied to the splitter cylinder cover port (1), moving the piston forward, engaging splitter gearing (2).
175
