System Components A-5013/A-6913 Roadranger Valve Constant air pressure is supplied from the slave valve to the roadranger valve “S” port (1). For LO range direct (range lever down (2), actuator button rearward (3),air flows out of the Roadranger valve “P” port (4).
For HI range direct (range lever up (2), actuator button rearward (3),the lever prevents the air from passing through the Roadranger valve (4).
145
System Components
For LO range overdrive (range lever down (2), actuator button forward (3) air flows out of the roadranger valve “P” port and “SP” port (4).
