Agrokid 50 Section: ENGINE
SUBAS: 00
Ref. 28
OIL PIPES FOR TURBOCHARGER CANALISATIONS D'HUILE POUR TURBO ÖLLEITUNGEN FÜR TURBOLADER Fig Part Nr Renewal time (d/h)
1 2 3 4 5
Qty
Description
Dénomination
Bezeichnung
0.010.3988.2 0.010.2681.2 0.009.4843.1 0.009.4843.0 0.010.3989.0
1 1 2 1 1
tube pipe fitting gasket pipe union tube
tuyau raccord joint raccord banjo tuyau
schlauch anschluss dichtung einfuellstutzen schlauch
0.010.2224.0 0.010.2682.1 0.009.4630.2 0.010.2683.2 0.010.2684.0 0.009.4624.0 0.010.2684.1
1 2 1 2 1 1 1
gasket screw ring bracket screw nut washer
joint vis anneau petit etrier vis ecrou rondelle
dichtung schraube ring buegel schraube mutter scheibe
- T. = 1.0 6 7 8 9 10 11 12
307.6032.3.6
Sheet 1 F
