4WD - FRONT DRIVE AXLE

DIFFERENTIAL BEVEL GEAR PAIR

DIFFERENTIEL - COUPLE CONIQUE DIFFERENTIAL - KEGELRÄDERPAARUNG

Fig Part Nr Qty Description Renewal time (d/h) Dénomination Bezeichnung

1 0.000.0000.1 - not serviceable 1.1 0.008.7761.3/10 1 *bevel gear pas livrable nicht lieferbar couple conique kegelradgetriebe

- T. = 10.9 -> (8.0 + 2.9 [Cod. 0406])

1.2 0.008.7721.0/10 1 *differential carrier boitier de differen. differ.-gehaeuse 1.3 2.1599.447.0 2 *shouldered washer (35.2x59x2)anneau d'appui distanzring 1.4 0.008.7722.3 1 *crown wheel planetaire achskegelrad

- T. = 5.9 -> (3.0 + 2.9 [Cod. 0406])

1.5 0.008.6061.0 2 *shoulder epaulement schulterlager 1.6 2.1699.312.0 1 *pin (15x102) axe bolzen 1.7 2.1631.418.0 1 *roll pin (5x45) goupille elastique federstift 1.8 2.0139.026.1 10 *screw (m 8x20) vis schraube

4WD - FRONT REDUCTION GEARBOX

4WD - RÉDUCTEUR AVANT 4WD - VORDERES GETRIEBE

Fig Part Nr Qty Description Renewal time (d/h) Dénomination Bezeichnung

3 2.1539.126.0 2 oil seal (183.82x2.62) joint d'étanchéité Dichtring 5 2.2045.011.0 2 ball bearing (35x72x17) roulement a billes kugellager 6 2.1411.029.1 2 circlip (72) anneau elastique sicherungsring 7 2.1499.116.0 4 ring (30x40x5) anneau ring 8 0.008.7728.3/10 2 bevel gear (z = 12 - 41) couple conique kegelradgetriebe

- T. = 4.1 -> (4.0 + 0.1 [Cod. 0901])

9 2.2040.009.0 2 ball bearing (iso 30 bc 02) roulement a billes kugellager 10 2.1470.004.2 18 lock washer (8) rondelle eventail zahnscheibe 11 2.0112.209.2 18 screw (m 8 p 1.25x25) vis schraube 12 0.008.7675.0/30 2 support support halter

- T. = 2.1 -> (2.0 + 0.1 [Cod. 0901])

13 2.2030.008.0 2 ball bearing (35x62x14) roulement a billes kugellager 14 0.008.7729.3 2 bevel gear couple conique kegelradgetriebe 15 0.013.2824.0/10 2 reduction box boitier reducteur untersetzergehaeuse

- T. = 3.1 -> (3.0 + 0.1 [Cod. 0901])

16 2.2030.013.0 2 ball bearing (60x95x18) roulement a billes kugellager

- T. = 3.1 -> (3.0 + 0.1 [Cod. 0901])

18 2.1411.032.1 4 circlip (80) anneau elastique sicherungsring 19 2.2030.011.0 4 ball bearing (50x80x16) roulement a billes kugellager

- T. = 3.1 -> (3.0 + 0.1 [Cod. 0901])

20 2.1419.068.0 2 circlip (50x24) anneau elastique sicherungsring 21 0.008.7730.0 2 shaft arbre welle 25 2.1580.207.0 3 shim (66x79x0.5) cale distanzring 26 2.3179.014.0 2 plug bouchon stopfen 28 2.1580.135.0 4 shim (40.5x48x0.15) cale distanzring 29 2.1580.105.0 4 shim (40.5x48x0.2) cale distanzring 30 2.1580.106.0 2 shim (40.5x48x0.50) cale distanzring 31 2.2040.012.0 2 ball bearing (iso 40 bc 02) roulement a billes kugellager 32 2.1560.008.0 2 gasket (12.2x18) joint dichtung 33 2.3110.402.7 2 plug (m 12 p.1.5) bouchon stopfen 34 2.1549.577.2 2 spacer (95x99.7x5) entretoise zwischenrohr 35 2.1529.158.0 2 oil seal joint d'étanchéité Dichtring
