Agrokid 30 40 50 Section: BODY WORK
SUBAS: 88
Ref. 186
COLLECTION TANK CUVE DE RÉCUPÉRATION ÖLAUFFANGWANNE Fig Part Nr Renewal time (d/h)
1
Qty
Description
Dénomination
Bezeichnung
0.013.6570.4/20 1
cup
cuvette
wanne
0.013.6749.3 0.013.6829.3 2.0020.109.2 2.1499.215.0 2.1312.003.2 2.1120.003.2 2.6857.017.0 0.013.6765.0 0.013.6764.0
1 1 2 2 2 2 2 1 1
tube pressure pipe screw (m 6x40) washer (8.5x20x1) washer (6.6x18) selflock nut (m 6) clamp (13) tube (mm 8x13x600) tube (mm 8x13x1000)
tuyau schlauch tuyau d'alimentationdruckrohr vis schraube rondelle scheibe rondelle dichtscheibe ecrou autobloquantselbstschlussmutter collier schlauchklemmen tuyau schlauch tuyau schlauch
0.009.0890.0 2.6852.101.0 2.1530.039.0 2.6857.013.0 0.012.4975.0
1 3 2 1 1
terminal clamp oil seal (15.6x1.78) clamp tube (mm 4x6x50) 1124 <- X Agrokid 30 1152 <- X Agrokid 40 1190 <- X Agrokid 50
cosse collier joint d'étanchéité collier tuyau
- T. = 0.3 2 3 4 5 6 7 8 9 10 - T. = 0.3 11 12 13 14 15
307.6032.3.6
anschlussklemme schlauchklemmen Dichtring schlauchklemmen schlauch
Sheet 1 F
