STEERING
f'^V
GENERAL DESCRIPTION The steering system consists of a collapsible steering column assembly, an intermediate shaft assembly and a rack and pinion type steering unit.
r
The steering column assembly is supported in the passenger compartment with an adjustable (up and down) bracket. Each end of the steering column shaft is splined. The upper splined end is designed to accept the steering wheel. The lower splined end of the steering column shaft fits through an opening in the driver's foot well and is sealed with a gasket and plate. The lower end of the steering column shaft is secured to the upper universal joint of the intermediate shaft. The lower universal joint of the intermediate shaft is secured to the splined stub shaft of the steering gear. The steering unit consists of a rack and pinion assembly, tie rod assemblies and tie rod ends. Each end of the rack and pinion assembly is protected from the elements with a flexible rubber boot which is secured with two (2) clamps. The adjustable tie rod ends, for obtaining proper toe-in specifications, are fastened to the steering knuckles.
