3 - ASSEMBLY
Control lever installation Removal of control lever (right) 1. Roll up the boot (*1) of the control lever and use the Phillips screwdriver or box wrench 10 mm to remove the 2 bolts (*2) of the console top cover.
SMIL14II00167AB
1
SMIL14II00168AB
2
SMIL14II00169AB
3
SMIL14II00170AB
4
2. Use the Phillips screwdriver to remove the 2 screws (*3), and then remove the handle of the tilt lever (*4).
3. Use the Phillips screwdriver to remove the 2 screws (*5) of the console top cover.
4. Remove the connectors (*6) and remove the console top cover (*7).
3-23 EN
