4 - ASSEMBLY
22. Connect the hose (28) between the condenser (25) and the filter (26). Connect the hose (30) to the condenser (25). Connect the hose (14) to the filter (26) and route it along the frame up to the top of the cab, before connecting it to the bottom of the air conditioning assembly (56). Fasten the hoses by means of the flange valve kit (27). NOTE: Before connecting the hoses, lubricate the O-rings.
RAIL14TLB0662BA
7
RAIL14TLB0663BA
8
RAIL14TLB0664BA
9
23. Remove the operator's seat. Remove the panels from the right and left posts inside the cab, remove the inner cab roof panel and remove the right side panel. NOTE: Discard all of the trim buttons that were removed. 24. Bore the cab roof panel and install the vents (60) and (61). Place the hoses (57) and (58) onto the roof panel. Connect the hoses (57) and (58) to the vents (60) and (61) by means of the clamps (51). Connect the hoses (57) and (58) to the cab roof by means of the cable ties (50).
25. Install the diffusers (59) onto the vents (60) and (61) by means of the screws (68). Position and fasten the roof panel by means of the plugs (55).
