02 Transmission/clutch 02 22 Hydraulic reverser
Input nose of the casing without doubler Exploded view
19
4 2
39 32 29
40
41
6 Fig. 3
321msm2b
Description 1 Needle stop.
16 Circlip.
31 27 tooth sun gear.
2 Input unit.
17 Needle stop.
32 Needle stop.
3 Brake piston.
18 Washer.
33 15 and 17 tooth double planetary gear.
4 O-ring.
19 Unit.
34 Needle cage.
5 O-ring.
20 Planet-carrier unit.
35 Spacers.
6 Screw.
21 Circlip.
36 Pin.
7 Guide.
22 Backplates.
37 Pin.
8 Ring.
23 Friction disks.
38 Thick backplate.
9 Clutch piston.
24 Piston support plate.
39 Needle bearing.
10 Seal.
25 Belleville washers.
40 Sleeve.
11 O-ring.
26 Shim.
41 Plug.
12 Belleville washers.
27 Washers.
13 Circlip.
28 Needle stop.
A Dual range unit brake.
14 Backplates.
29 Washer.
B Dual range unit planet gears.
15 Friction disks.
30 25 tooth sun gear.
C Dual range unit clutch.
78
Axos 340-310 – 08.2009 – GB
