02 Transmission/clutch 02 20 Doubler and mechanical reverser
Adjusting the external reverser control
14
12
9
12
13 6 mm
10 11
Fig. 8
323msm0x
– Remove the left-hand instrument panel lining. – Check that the threading (9) of the control cable protrudes by 20mm from the locknut. – Remove the axis of the lower yoke (10) on the gearbox side. – Pull back the reverser lever (11) until the reverse gear is locked.
– Check in the cab that a 6mm gauge can be inserted between the edge of the lever (12) and the lever support slit (13). – Adjust the adjustment using nuts (9) of the sheath. Note: After adjusting, check that the lever (12) does not interfere with the bellow holder (14) in the forward or reverse position.
– Refit the yoke onto the lever.
Axos 340-310 – 08.2009 – GB
73
