02 Transmission/clutch 02 20 Doubler and mechanical reverser
Description 1 Access box housing and engine housing.
A Tightness torques of screws on cover: 8 ± 1,5 daN·m. Gasket face: Loctite (518).
2 Access box housings and gearboxes. 3 Front and rear axle gearbox sumps.
Preparation - Preliminary operations – Remove the cab. Refer to the part: 02 10 Full cab removal – Operations 1 to 15. – Disconnect the clutch housing from the engine. Refer to the part: 01 02 Removing the engine – Operations 1 to 26. – Separate the clutch housing from the gearbox housing.
Axos 340-310 – 08.2009 – GB
69
