02 Transmission/clutch 02 15 Mechanical clutch
Removing the clutch stop and guide Note: The operations described below apply to all types of mechanically controlled clutch.
19
18
– Disconnect the tractor between the engine and gearbox. – Free the release bearing operating arms. – Advance the release bearings by manually operating the controls (23) and (24). – Remove the two fasteners (29) attaching the vehicle drive fork (24) to the vehicle drive release bearing support (21).
24
– Remove the two fasteners (29) attaching the PTO fork (24) to the PTO release bearing support (21). – Extract both release bearing supports (21) and (20) by sliding them forwards along the clutch guide (22). 301msm07
– Remove the vehicle drive release bearing (18). – Remove the PTO release bearing support (21) by sliding it along the vehicle drive release bearing support (20). – Remove the PTO release bearing (19). – Remove the clutch guide (22) by extracting its attachment screws. – Extract the seal (25) fitted on the forward drive shaft (16).
Refitting the clutch stop and guide – Proceed in reverse order to dismantling. – Replace the seal (25). – Grease the bearing sleeve. – Refit the clutch guide (22) to the gearbox casing, tightening its attachment screws to a torque of 4,5 ± 0,5 daN·m. – Reassemble the operating arms on the clutch levers (23) and (24). – Adjust the controls if required.
48
Axos 340-310 – 08.2009 – GB
Fig. 15
