02 Transmission/clutch 02 15 Mechanical clutch
Refitting the shaft of the PTO clutch – Always change the needle cage (9).
– Insert the PTO shaft (1) inside the shafts.
– Always change the gasket (7)
– Refit in sequence the circlips (5) and (6) the shim(s) (4), the cover (3) and the circlip (2).
– Slightly oil before refitting.
Axos 340-310 – 08.2009 – GB
47
