02 Transmission/clutch 02 15 Mechanical clutch
Adjusting the clutch release levers
77 01 388 435 DT 310/310 G
60 05 005 900
77 01 388 430
77 01 388 430
Fig. 13
301msm24
– Fit the centering tool No. 77 0138 843 5 and stop hub No. 60 0500 590 0, adjustment template No. 77 0138 843 0. Note: The template fitted is calibrated to the dimension of the release levers.
– Tighten the three screws (11) on the vehicle drive release levers until resistence is felt then tighten the lock nuts (12) taking care not to move the template (Use a thin shim). Lock the nuts using Loctite (243). – Re-attach the gearbox casing to the engine crankcase.
– Bear the template against the flywheel (1). – Tighten the three PTO release lever nuts (10) until resistance is felt taking care not to move the template (Use a thin shim). Lock the nuts using Loctite (243).
– Re-tighten the casing attachments to a torque of 6 to 8 daN·m.
