02 Transmission/clutch 02 30 Mechanical reducer
Lubrication
0,5 daN.m
3 4
2
8 0,5 daN.m 0,5 daN.m
1 2,2 mm
7
5
6 Fig. 21
323msm1g
Description 1 Unit.
4 Pipes.
7 T junction. Calibrated at 2,2 mm.
2 O-ring.
5 Pipes.
8 O-ring.
3 Elbow coupling.
6 O-ring.
Fitting the internal lubrication circuit – Fit the elbow (3) with a new and greased gasket (2). – Check that the calibrated port of the T (7) is not clogged.
126
Axos 340-310 – 08.2009 – GB
