02 Transmission/clutch 02 30 Mechanical reducer
1
2
3
4
5
6
7
12
11
10
8 9
16 17
13
19
14
15
22
20 21
25
24
23
Fig. 6
323msm88
Description 1 Washer.
9 Cotter.
17 Needle cage.
2 Washer.
10 Synchro hub.
19 Synchro hub.
3 Tapered roller bearing.
11 Sliding gear.
20 Spring.
4 Primary shaft.
12 Synchro ring.
21 Cotter.
5 Needle cage.
13 Synchro ring.
22 Sliding gear.
6 Pinion.
14 Synchro ring.
23 Synchro ring.
7 Synchro ring.
15 Pinion.
24 Tapered roller bearing.
8 Spring.
16 Plain bush.
25 Pinion.
Removing the rear intermediate shaft – Remove the circlip (32) and the shims (31). – Always replace the O-ring seal (29).
112
Axos 340-310 – 08.2009 – GB
