02 Transmission/clutch 02 30 Mechanical reducer
Description 33 Internal circlip.
42 Spring.
52 Pinion.
34 Shim (Thicknesses available : 0,10 ; 0,15 ; 0,50 ; 2,00).
43 Cotter.
53 Spacer.
44 Synchro hub.
54 Pinion.
45 Sliding gear.
55 Spacer.
46 Synchro ring.
56 Pinion.
47 Synchro ring.
57 Needle bearing.
48 Synchro ring.
58 Tapered roller bearing.
49 Pinion.
59 Shaft.
35 Tapered roller bearing. 36 Bush. 37 Needle cage. 38 Pinion. 39 Synchro ring.
50 Bush.
40 Synchro ring.
51 Needle cage.
41 Synchro ring.
Secondary gear train – Secondary shaft
72 71 70 69 68 67 66 65
64 63 60
62 61 Fig. 4
323msm1a
Description 60 Synchro ring.
65 Pinion.
61 Cotter.
66 Needle cage.
69 Shim (Thicknesses available : 0,10 ; 0,15 ; 0,20 ; 0,50 ; 1,00).
62 Spring.
67 Pinion.
70 Dual taper bearing.
63 Synchro hub.
68 Nut.
71 Cover. 72 Drive pinion.
64 Sliding gear.
