02 Transmission/clutch 02 30 Mechanical reducer
Description 1 Flange.
8 Spring.
15 Pinion.
2 Washer.
9 Cotter.
16 Plain bush.
3 Tapered roller bearing.
10 Synchro hub.
17 Needle cage.
4 Primary shaft.
11 Sliding gear.
18 Plain bush.
5 Needle cage.
12 Synchro ring.
6 Pinion.
13 Synchro ring.
A Gearbox without low range.
7 Synchro ring.
14 Synchro ring.
B Gearbox with low range.
Primary gear train – Rear intermediate shaft
32 31 30 29 28
27 26
21 20 25 24 23
22 19 Fig. 2
323msm38
Description 19 Synchro hub.
24 Tapered roller bearing.
29 Seal.
20 Spring.
25 Pinion.
30 Tapered roller bearing.
21 Cotter.
26 Cylindrical bearing.
22 Sliding gear.
27 Rear intermediate shaft.
31 Shim (Thicknesses available : 0,10 ; 0,15 ; 0,50).
23 Synchro ring.
28 Needle bearing.
32 Internal circlip.
Axos 340-310 – 08.2009 – GB
107
