15 Maintenance
15 Maintenance 15.3 Lubricants chart
15.3 Lubricants chart Component
Filling quantity
Lubricant type & specification
Rear angle drive
0.85 liters
Hypoid gear oil
Front angle drive
2.50 liters
(MIL-L-2105B)
Viscosity/SAE Change interval/ class checks
Gear drives
SAE 90
See Maintenance schedule.
API-GL-5-90 Rotor drive
7.0 kg in each
See Maintenance schedule.
Low-viscosity grease NLGI class 00/000 ESSO EP 4223 DIN 51 502 – GP 00/000 H-30 or SHELL Retinax G DIN 51 502 – G 00F Order no.: Retinax G: 0.5 kg tin 0177 459.0 20 kg container 0178 672.0
Lubrication points Grease nipples
Branded multi-purpose grease DIN 51825 - K2K CLAAS multi-purpose grease EP2 KP 2K-30 Order no.: 400 g cartridge
Other lubrication points
See Lubricating chart.
0147 451.0
Bio-degradable lubricating oil CEC-L-33-A-93 > 80% CLAAS roller chain oil BIO HEES 46 Order no.: 5 ltr. PE canister
See Lubricating chart.
0147 457.0
Note! The indicated filling quantities are approximate values; the oil level check is always decisive to maintain a correct oil level.
0293 133.6 - BA LINER 3000
147
