14 Trouble shooting
14 Trouble shooting 14.2 Error messages in the display (swather with ISOBUS Terminal)
14.2 Error messages in the display (swather with ISOBUS Terminal) Error message 1: Danger! When raising/lowering the rotors, make sure that nobody is in the pivoting area. There is a risk of injury. – Direct all persons out of the danger area. – Switch off the machine at once, if necessary. – If necessary, interrupt the control unit with the “STOP” key.
1
Never work on the machine while the tractor's engine is running. – Switch off the engine. – Remove the ignition key. Initialization is started with running/overrunning PTO shaft.
• Disengage the PTO shaft. – The display changes to the start window, seefig. 12, see 82.
• Press the “Soft Key”: The display changes to the start window, seefig. 12, see 82. The display changes to the info window, seefig. 16, see 83. (Fig. 1)
Error message 2: The control system has recognised the following error: – The rotors should be automatically lifted above the max. headland position (transport position) with the PTO shaft running/overrunning. – The process is stopped.
• Disengage the PTO shaft. – After the PTO shaft comes to a standstill the display changes to the screen “Automatically raise to transport position” seefig. 11, page 51. 2
Push the “Soft Key”, the display changes to the start screen, see fig. 12, page 82. (Fig. 2)
142
BA LINER 3000 - 0293 133.6
