Preliminary set-up 34
95
35
Connecting the operating unit (82) and the operating unit cable (83)
96
Fit the operating unit holder (95/96) to the bracket (31).
32
33 103 104
31
(103) Cheese head screw
(M5x16)
4x
(104) Contact washer
(A5)
4x
(105) Lock nut
(VM5)
4x
(Fig. 14-16)
105 14
Screw the bracket (31) for the operating unit (82) on to the right hand side frame member of the cabin.
31
(32) Hex head self tapping screw (ST4.8x16-C) 3x
34
35 33
(33) Contact washer
(A5)
3x
(34) Stop buffer
(D18x7.5)
2x
(35) Hexagonal nut
(M6)
4x
Adjust the stop buffer (34) so that the bracket is slightly under tension.
32 15
(Fig. 14-16)
Place the operating unit (82) in the holder. (Fig. 15 = Contents of bag (936 798.0) - JAGUAR Model 492 conversion parts) (Fig. 16 = Contents of bag (936 607.0) - JAGUAR Model 492/491 electrics)
103 105 104
16 Pull off the rubber seal (G) in the front right hand corner (arrowed) of the central electrics area. Saw out a notch for the cable (83) to the operating unit (82) and then re-lay the rubber seal (G).
83
(Fig. 17) G
17
R
492 CONTROL TERMINAL
JAGUAR 8700 / 900 / 890 / 870 / 850 / 830
6.6
