5 General preparation The DISCO 8700 C Plus / 8700 C mower unit is intended for operation with the JAGUAR Model 492 and Model 491. The following measures must be carried out on the JAGUAR before fitting the DISCO 8700 C Plus / 8700 C.
HYDRAULIC SYSTEM The supplied double-acting lifting cylinders must be fitted to the JAGUAR. JAGUAR Model 492: – see Hydraulic system, page 6.12 JAGUAR Model 491: – see Hydraulic system, page 6.26.
TYRES Only radial tyres are permissible at the front; water-filled tyres must be used at the rear.
ADDITIONAL WEIGHTS Additional weights must be fitted to the JAGUAR to ensure adequate loading of the rear axle. JAGUAR Model 491: JAGUAR 820 with four-wheel drive:
13 additional weights
JAGUAR 820 without four-wheel drive:
14 additional weights
JAGUAR 840, 860, 880 with four-wheel drive:
12 additional weights
JAGUAR 840, 860, 880 without four-wheel 13 additional weights drive: JAGUAR Model 491 Overdrive: with four-wheel drive:
13 additional weights
without four-wheel drive:
14 additional weights
JAGUAR Model 492 (40 km/h): with four-wheel drive:
12 additional weights
without four-wheel drive:
13 additional weights
JAGUAR Model 492 (20 km/h):
5.1
with four-wheel drive:
10 additional weights
without four-wheel drive:
11 additional weights
