Prior to Operation CONVERSION FROM PUSHED COMBINATION TO FRONT - REAR COMBINATION Danger! Before starting the fitting work, turn the tractor engine off. – Remove the ignition key!
Danger! Before starting the fitting work, release the suspension springs on both sides.
Hinge up the side mower units. Release the lock nuts (1). 3
Completely unscrew the bolts (2) out of the suspension springs (3). Tie the levers (4) of the suspension together using suitable straps (e.g. cable ties).
1
Lower the side mower units. (Fig. 140)
2
4
6.61
140
ZBA+BA DISCO 8550 C Plus / 8550 C / 8550 Plus / 8550 / 8550 C-T / 8500 C - 000 295 331 0
