Prior to Operation DISCO 8550 C Plus / 8550 C / 8550 C-T
Note! DISCO 8550 C Plus / 8550 C / 8550 C-T: If the machine is at a standstill for a longer period of time, the check lamp (6) on the control terminal must be out. The electrical connection to the tractor must be interrupted.
6
(Fig. 130)
130
Lowering the machine in the folded condition
Danger! Gusts of wind and uneven or soft ground can cause the lowered machine to tip over. – Only store the machine in the folded condition in an equipment shed. (Fig. 131)
131 DISCO 8550 C Plus / 8550 C / 8550 C-T
•
Hinge the mower unit into the transport position
• Slide the stands (1) downwards and locate in position with the pin. (Fig. 132)
• Lower the mower unit down to the ground using the three point linkage. 1
• Move the single-acting control valve to the 0 posi-
1
tion (neutral). 132
• •
Push this button. The lamp lights up green. Push both these buttons. Both lamps light up red.
000 295 331 0 - ZBA+BA DISCO 8550 C Plus / 8550 C / 8550 Plus / 8550 / 8550 C-T / 8500 C
6.56
