Prior to Operation ATTACHMENT TO THE TRACTOR The DISCO 8550 C Plus / 8550 C / 8550 C-T and 8500 C can be operated as a large area mowing combination in two types of mountings:
A
Note! The DISCO 8550 Plus / 8550 cannot be used as a pushed combination and can only be used as a trailed front-rear combination.
113
64461R/01
As a towed combination, the fitting frame is hooked in with the side mower units in Position A. The front mower unit is mounted on the front on the tractor. (Fig. 113)
As a pushed combination, the fitting frame is hooked in Position B on a tractor with reversing facility. In this case, the front mower unit is mounted onto the fitting frame via an adapter.
B
(Fig. 114)
64462R/01
114
000 295 331 0 - ZBA+BA DISCO 8550 C Plus / 8550 C / 8550 Plus / 8550 / 8550 C-T / 8500 C
6.48
