Prior to Operation Push back the universal drive shaft guard (S). (Fig. 64)
S 64
4
Fit sensor (1) to the gearbox with sensor bracket (2), hexagon head bolts (3) and contact washers (4).
1
(Fig. 65)
3
2
65 Setting the height of the sensor (1). M
To do this, release the hex nuts (M), move the sensor (1) in the required direction and re-tighten the hex nuts (M).
1
Tightening torque of the hex. nuts (M) = 15 Nm 4 mm
The distance between the sensor (1) and a tooth on the universal drive shaft (W) should be approx. 4 mm. (Fig. 66)
W 66 Then set the distance from the sensor (1) to the carrier bracket (A) of the universal drive shaft. This is done by displacing the sensor bracket (2) in the slotted holes. A
1
(Fig. 67, 68) The distance between the sensor (1) and the slip-on coupling (A) should be 2-4 mm. (Fig. 67)
2-4 mm 67
6.29
