Bucyrus International, Inc. 495HD Electric Mining Shovel
OPERATOR’S SEAT
Operator’s Seat - Front View
The operator’s seat has been selected to provide a maximum of operator comfort along with easy control access for increased productivity. The seat has numerous adjustments allowing it to be tailored to meet the individual needs of each operator.
Weight Adjustment The seat should be adjusted for the operator’s weight by pulling the actuator lever of the automatic weight and height adjuster while the operator is sitting in the seat and the machine is stationary.
Height Adjustment The seat height is adjusted pneumatically by pulling or pressing the adjustment lever as required to obtain the position required. DO NOT operate the compressor unit for more that 1 minute continuously.
Aug. 2008
51
Manual No. 10648
