OPERATING INSTRUCTIONS RH 90 C E Operation EMERGENCY STOP pushswitch The entire electrical system is switched off with the EMERGENCY STOP pushswitches. In an emergency, press the EMERGENCY stop. The EMERGENCY STOP pushsbuttons are located
in the control column in the driver's cab (31, Fig. 2-15:)
Fig. 2-17:
The electrical system of the excavator can be switched on after the EMERGENCY SHUTOFF buttons are activated. Â Pull the buttons out. Switch – servicing works
Fig. 2-15:
in the control cabinet (3, Fig. 2-16:)
In an emergency the electric motor can switched off with switch (4, Fig. 2-16:) In an emergency, press the button (4). The electrical system of the excavator can be switched on after the button is activated: Â Pull the buttons out.
Fig. 2-16:
under the hydraulic tank (6, Fig. 2-17:). The pull switch is is operated by a string (5).
BA RH90C(3 720 760.00)-EN
2-17
