OPERATING INSTRUCTIONS RH 90 C E Operation Access lighting
Cab interior lamp
The access can be illuminated in the dark.
The interior lamp is switched on and off with switch (1, Fig. 2-10:).
Fig. 2-9:
The access lighting is switched on by a pull switch (2, Fig. 2-9:).
Fig. 2-10:
Switch position 0 - lamp off
The pull switch is located under the couterweight and can be activated by pulling the rope (1).
1 - lamp on. The interior lamp can be used even if the electrical system is switched off. Therefore, switch off the interior lamp when leaving the machine. The batteries may be discharged if the interior lamp is left on for prolonged periods. The interior lamp is also switched on and off with switch (3, Fig. 2-11:).
Fig. 2-11:
BA RH90C(3 720 760.00)-EN
2-15
