________________________________________ Replacement of wear parts How to disassemble the conveyor power unit (Fig. 94) WARNING! Before removing each pump and the connecting tube be sure to properly support the component. Failure to properly support the component may result in damage to the component or injury to personnel. WARNING! Remove all fittings from the pumps and plug the ports before removal. Failure to remove fittings and plug ports could result in damage to the pumps. 1. Remove two M10 bolts and spring washers and remove priority gear pump. Save the o-ring and splined pump insert from the rear of the open loop pump (Fig. 95). IMPORTANT! Remove and save the o-ring and splined pump insert from the rear of the open loop pump. Fig. 95: Open loop pump assembly
O-ring
Splined insert Open loop pump Bolt (2)
Spring washer (2)
Priority gear pump
