Every 2500 hours...........................................................5

Maintenance _____________________________________________________

hydraulic oil water filter The hydraulic oil water filter is located on the left side of the machine and is mounted to the hydraulic oil tank (Fig. 50). The filter is monitored by the PLC and when the filter reaches 60% capacity, an alarm will be displayed on the PLC view panel, located on the right side of the machine on the starter enclosure (Fig. 49). The alarm will display on the ‘MAIN SCREEN” and will read “HYDRAULIC OIL WATER REMOVAL FILTER DIRTY”. When the alarm is displayed, the filter should be changed.

Fig. 50: Water filter location

Water filter
