____________________________________________________ Maintenance tail shaft and slide tube bearings
Lubricate the feeder breaker tail shaft and slide tube bearings with Spec. 100-3 through the grease fittings located on right side of the machine at the primary operator’s station (Fig. 44). Pump grease into the four (4) fittings until new grease can be observed coming out of the tail shaft and bearings. To see the bearings, the tail shaft cover (Fig. 46) must be removed.
Fig. 46: Tailshaft and slide tube bearings
Grease fittings location (4)
Tail shaft bearing location
Tail shaft bearing location Slide tube bearing location
Slide tube bearing location
