LUBRICATION/FILTERS/FLUIDS
FUEL SYSTEM Draining water and sediment from the fuel tank.............................. Every 50 hours Draining water from the water separator ......................................... Every 50 hours Cleaning of water separator filter .................................................. Every 500 hours Fuel filter replacement................................................................... Every 500 hours Cleaning the priming pump screen ............................................. Every 1000 hours Fuel hoses replacement.................................................................... Every 2 years or every 4000 hours (whichever comes first) Fuel tank capacity .....................................................................................611 litres Type of fuel ................................................................... See "Fluids and lubricants"
Draining water and sediment from the fuel tank
Draining water from the water separator
2
A
TRIM THIS EDGE
The water separator is located in the rear compartment of the machine.
Alt= to hide template information Alt+ to display template information
Service specification
1 CD01K077
Position a drain pan under the drain plug.
After draining, close the drain valve.
When the float reaches the level line (A) Loosen the drain plug (1) and drain the water and sediment. When the float (2) settles on the bottom, tighten the drain plug (1). Verify that there are no fuel leaks.
!
WARNING: Completely wipe off any spilt fuel. It may cause a fire.
151
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
Open the drain valve located at the bottom of the tank and drain the accumulated sediment and water.
CD01K078
