OPERATING INSTRUCTIONS
The load handling chart (located in the cab) shows the different permitted loads which can be lifted, depending on the reach and the type of attachment on the machine. The machine must be on a flat, level, hard surface. Loads are in kg for a machine with tool, bucket cylinder completely extended and for full upperstructure swing, with a builtin safety margin factor of: - 33% on stability,
taking the connecting rod eye as the load fixing point.
CS00E556
IMPORTANT: The values given must be reduced to take into consideration the weight of the quick coupler (if fitted) and the clamshell mounting adaptor. See "Weights" in the "Specifications" Section. NOTE: The loads given are valid for the total working range height at the reach point indicated.
TRIM THIS EDGE
- 15% on hydraulic limits,
Alt= to hide template information Alt+ to display template information
LOAD HANDLING LIMITS
Template Name: OM_1_col Template Date: 1994_04_29
NOTE: The lifting capacity of the quick coupler (optional) load handling eye is: 10 tonnes.
