9 - ACCESSORIES
Attachment disengagement WARNING Misuse hazard! Follow the operating instructions in this chapter. Any other practice that has not received the prior approval of the manufacturer is considered to be strictly forbidden. Failure to comply could result in death or serious injury. W0281A
WARNING Impact and crushing hazard! The attachment can swing from one side during the removal procedure. Keep clear of the attachment, including the swing area. Failure to comply could result in death or serious injury. W1492A
NOTE: Before to disengaging the attachment, Fully extend bucket crowd cylinder. To disengage the attachment from the quick coupling system: 1. Fully extend the bucket cylinder. 2. Slide the switch mechanism (A) , then press and hold the hydraulic quick coupling activation switch (B) in release position for 2 s. NOTE: to disengage the attachment is necessary keep pressed the hydraulic quick coupling activation switch (B). SMIL17MEX2829AA
11
SMIL16MEX3181AA
12
3. Hold the bucket curl lever for approximately for 3 – 5 s to allow the hook to fully retract place coupler in the fully curled position. 4. Release the quick coupling activation switch (B).
WARNING Impact and crushing hazard! Never use ladders or other means to disengage the attachment. Keep clear of the attachment during the disengagement procedure. Failure to comply could result in death or serious injury. W1493A
9-42
