9 - ACCESSORIES
Second auxiliary hydraulic circuits (4-way) The machine can be provided with an additional second auxiliary hydraulic circuit. This type of circuit can operate the attachments featuring secondary hydraulic actuation for positioning, such as rotating grabs or tilt able buckets.
Hydraulic connections The two feed lines are located on each side of the arm under first auxiliary hydraulic circuit to allow proper and safe connection of the attachment hydraulic lines to the second auxiliary hydraulic circuit.
SMIL18MEX0873BA
Hydraulic connection (A)
6
Quick coupling fitting
Operational settings The flow rate/pressure characteristic of the second auxiliary hydraulic circuit is set by means the engine power applied. The second auxiliary specifications for second auxiliary circuit are set from factory: maximum flow rate (P2+P3) maximum operating pressure (P3)
46 L/min (12.2 US gpm) 175 bar (2537.5 psi)
9-8
