CONTROLS/INSTRUMENTS/ACCESSORIES
ENGINE HOOD Opening
Closing
Template Name: OM_1_col Template Date: 1994_04_29
2
1 CD01K033
CD01K034
TRIM THIS EDGE
To open the hood, pull the handle (1) behind the cab lower panel (2). Raise the hood completely until the strut locks automatically in position. Use the starter switch key to open and lock the panel (2).
!
Raise the hood slightly, pull the strut back and then lower the hood and slam it shut.
!
WARNING: Before undertaking any travel, make sure the hood is properly closed.
WARNING: Once the hood is completely opened, make sure the locking system is correctly engaged.
