CONTROLS/INSTRUMENTS/ACCESSORIES
3. Hold both handles (3) and carefully lower the windshield. Make sure the window is completely down.
Release the right-hand latch (4).
4. Make sure the top of the windshield is correctly latched.
5 CD00E020
2. Use the lever (5) to release the windshield. TRIM THIS EDGE
LOWER FRONT WINDOW The lower front window may only be removed when the windshield is open.
CD00E021
CD00E022
1. Push the right-hand and left-hand latches and remove the window.
2. Place the window in the storage position provided to the left of the operator’s seat and then engage it correctly.
67
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
1.
Alt= to hide template information Alt+ to display template information
Closing
