CONTROLS/INSTRUMENTS/ACCESSORIES
Operator’s seat (continued) The seat belt must be kept clean. Use only soap and water to clean the belt, do not use bleach or dies.
Template Name: OM_1_col Template Date: 1994_04_29
IMPORTANT: Inspect the seat belt. Make sure that it is not damaged, that the mounting screws are correctly tightened and replace any defective parts.
WINDSHIELD
!
WARNING: Make sure you follow the instructions below properly. If the windshield is not handled correctly it could slip and injure your fingers or hand.
Opening
2 TRIM THIS EDGE
4
1 CD00E023
CD00E019
Alt= to hide template information Alt+ to display template information
1. Fold back the sunshield (1) against the windshield and pull the lever (2).
3. Engage the right-hand latch (4) in the cab upright.
3
CD00E047
2. Hold the lower and upper handles (3) and carefully raise the windshield. Push to the rear until it engages.
66
