ELECTRICAL SYSTEM
Replacing a bulb (continued) Template Name: OM_1_col Template Date: 1994_04_29
Upperstructure and cab headlight
CD00E129
4. Remove the four screws and tilt the headlight. CD00E053
1.
Open the front box.
TRIM THIS EDGE
Alt= to hide template information Alt+ to display template information
CD00E130 CD00E127
2. Take out the windshield washer reservoir to gain access to the headlamp.
5. Pull the clip outwards, remove the bulb and install a bulb of the same wattage (70 W). IMPORTANT: Never put your fingers on a tungsten iodide bulb. 6. Install the clip, put the headlamp back in position and install the screws and the plug. 7. Put the windshield washer reservoir back in place.
CD00E128
3.
Disconnect the plug.
208
