MAINTENANCE/ADJUSTMENTS
REPLACING A TOOL ON A HYDRAULIC BREAKER (optional) Template Name: OM_1_col Template Date: 1994_04_29
Removal
CP99C005
CP99C007
1. Place the hydraulic breaker laying on hard, flat ground.
4. Drive out the mounting pins with a bronze or brass drift.
TRIM THIS EDGE
2. Stop the engine and remove the starter switch key.
Alt= to hide template information Alt+ to display template information
CP99C008
5. Remove the tool. Use a lifting device if necessary.
CP99C006
3. Push the rubber plate upwards (if fitted). Remove the retaining pins and plugs from both sides of the hydraulic breaker.
NOTE: If the hydraulic breaker is still on the machine, it may be easier to stick the tool in the ground and lift the hydraulic breaker off the tool. Make sure that the tool can not fall.
188
