LUBRICATION/FILTERS/FLUIDS
FUEL SYSTEM Draining water and sediment from the fuel tank.............................. Every 50 hours Draining water from the water separator ......................................... Every 50 hours Cleaning of water separator filter .................................................. Every 500 hours Fuel filter replacement................................................................... Every 500 hours Fuel hoses replacement.................................................................... Every 2 years or every 4000 hours (whichever comes first) Fuel tank capacity .....................................................................................340 litres Type of fuel ....................................................................See “Fluids and lubricants”
Draining water and sediment from the fuel tank
Draining water from the water separator A TRIM THIS EDGE
2
1
Alt= to hide template information Alt+ to display template information
Service specifications
CD00E108
Remove the panel located under the fuel tank and open the drain valve and drain the accumulated sediment and water. After draining, close the drain valve.
When the float reaches the level line (A) Loosen the drain plug (1) and drain the water and sediment. When the float (2) settles on the bottom, tighten the drain plug (1). Verify that there are no fuel leaks.
!
WARNING: Completely wipe off any spilt fuel. It may cause a fire.
151
TRIM THIS EDGE RIGHT PAGE
Template Name: OM_1_col Template Date: 1994_04_29
CD01K049
Have a container ready to collect the drained contaminants.
