LUBRICATION/FILTERS/FLUIDS
ENGINE Service specifications Template Name: OM_1_col Template Date: 1994_04_29
Engine oil level check..................................................Every 10 hours or every day Oil change ..................................................................................... Every 500 hours Oil filters replacement ................................................................... Every 500 hours Oil type ..........................................................................See “Fluids and lubricants” Oil capacity ................................................................................................. 24 litres
Level 1. Park the machine on flat, horizontal ground. Stop the engine and remove the starter switch key.
B A
1
1 TRIM THIS EDGE
2
CS98M579
3. If the oil level is below the mark (A) (minimum), remove the oil filler cap (2), add oil up to the mark (B) (maximum) on the dipstick (1) and then replace the oil filler cap.
CD01K010
Alt= to hide template information Alt+ to display template information
2. When the engine has been stopped for fifteen minutes, remove the dipstick (1), wipe it with a clean cloth and replace it in the guide tube as far as it will go. Then take it out again.
NOTE: The level should not be higher than the mark (B) (maximum) on the dipstick (1).
146
