OPERATING INSTRUCTIONS
HYDRAULIC BREAKER OR HIGH FLOW HYDRAULIC CIRCUITS (optional) Template Name: OM_1_col Template Date: 1994_04_29
Your machine has two types of auxiliary hydraulic circuit. One circuit is for single flow equipment, such as hydraulic breakers. The second circuit is for single flow or double flow continuous flow equipment, or double flow equipment such as concrete crushers. Consult your CASE Dealer for instructions on how to select the correct pressure for the optional tool.
Hydraulic breaker configuration
2 TRIM THIS EDGE
CD01K042
CD00E072
1. Make the necessary tool connection and then open the supply valves.
3. Tilt the control (2) on the left-hand arm to the right for hydraulic breaker operation.
Alt= to hide template information Alt+ to display template information
1
CD00E070
CD00E012
2. Remove the screw (1), place the flow selector valve in position (B) and then install the screw (1).
4. Use the control pedal to operate the hydraulic breaker. 5. Close the supply valves before removing the hydraulic hammer and then plug the supply valves. 6. Tilt the control (2) to the central position.
110
