OPERATING INSTRUCTIONS
!
WARNING: It is strictly forbidden for anybody to remain in the machine operating area during tool installation and removal operations.
Installation
1 CD00F030
CD01K005
2. Place the switch (1) in unlocking position. The audible alarm device will sound. See “Quick coupler locking and unlocking control switch” in the “Controls/ Instruments/Accessories” Section.
3. Operate the dipper and bucket controls so that the dipper is practically vertical, sloping slightly towards the cab to release the safety device. Extend the bucket cylinder rod completely and maintain the hydraulic pressure so that the latching hook retracts.
103
TRIM THIS EDGE RIGHT PAGE
TRIM THIS EDGE
1. Make sure the tool to be installed is laying safely on flat, level ground and that it is fitted with the pins supplied with the quick coupler.
Template Name: OM_1_col Template Date: 1994_04_29
IMPORTANT: This quick coupler is designed to be used with CASE buckets. This being said, other buckets may be used, provided the diameter of the pins and the width between the bucket lugs are modified to meet the dimensions needed to fit the quick coupler (pins, washers, bushings, etc...). See your CASE Dealer.
Alt= to hide template information Alt+ to display template information
QUICK TOOL INSTALLATION AND REMOVAL (optional)
